Industrial Single Head Sewing Embroidery Machine With Direct-Drive Motor

FOB Reference Price:Get Latest Price
US $20,000-30,000 / Set | 1 Set/Sets embrodery machine single head (Min. Order)
Supply Ability:
100 Set/Sets per Month embrodery machine single head
Port:
ShenZhen, China
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
YIBODA
Model Number:
D240A10
Max Sewing Speed:
2800rpm
Max Sewing Thickness:
≤60mm
Number of Head:
Single Head
Moving Style:
Head Moved
Voltage:
AC220/380V;2&3Phases;50Hz
Power(W):
5kw
Dimension(L*W*H):
3550*5000*1600MM
Weight:
2000kg-3000kg
Certification:
CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
key word:
embrodery machine single head
Certificate:
CE
Needle Type:
9#--16#
Quilting width:
2200*2400mm
Max Speed:
2800rpm
X Area:
250mm
Stitch Distance:
2-6mm
Product name:
industrial sewing machine direct-drive motor
Packaging & Delivery
Packaging Details
Industrial Single Head Sewing Embrodery Machine With Direct-Drive Motor;
export standard packing
Delivery Time
delivery: within 35 days after receive the deposit







Industrial Single Head Sewing Embrodery Machine With Direct-Drive Motor

Gross Power 5KW
Stitch Distance2mm--6mm
Needle Type9#--16#
Working Width2200*2400mm
Max Speed2800rpm
Power SupplyAC220/380V;2&3Phases;50Hz
Machine Size3550*5000*1600mm

·Quilting and Embroidery completed simultaneously.

·Driving by roller system without frame.

·Keep fabric smooth by Tensile Motor at the inlet and outlet fabrics.

·Keep embroidery  precision by Servo driving at x/y axis.

·Auto-trimming system(optional).

·Auto-stopping function once thread broken.

·Auto-return for patch-up embroidery function.

·Easy head selection for quilting function.

·Continuously quilting independent patterns function.

·Unique mechanical structure can diminish self-vibration and noises.

·Various materials are available for embroidery.

·Prepared some quilting embroidery patterns for your choice.
